Rocker Pin Compression Load Cell

Rocker Pin Compression Load Cell

118 USD ($)/Piece

Product Details:

X

Rocker Pin Compression Load Cell Price And Quantity

  • 118 USD ($)/Piece
  • 1 Number
  • 118.00 - 1180.00 USD ($)/Piece

Rocker Pin Compression Load Cell Trade Information

  • 500 Number Per Week
  • 45 Days

Product Description

WEIGH BRIDGE LOAD CELL

With most advanced infrastructure, we are offering the finest quality assortment of Weigh Bridge Load Cell. These are manufactured using the best quality raw materials and are fully supported by advanced features like auto power on/off system, high over load capacity, high strain gauge based load cell. Offered load cells are used for weighing heavy load of truck and tractors. Made of a special steel alloy, it is very robust and totally protected from lightning and electrical surges. Our environmentally friendly Weigh Bridge Load Cell gives maximum satisfaction to our precious clients due to its various features at reasonable prices.

Features:

  •  Higher strength
  •  Greater reliability
  •  Easy and faster installation
  •  Superb accuracy

New, compression Load cell Model HE-RC300.

Hariom Electronics, a well known Precision Load cells Manufacturing Company, have developed an ultimate Load Cell (Model HE-RC300).

Easy to install in

* An Electronic Weigh Bridge,

* Dynamic Rail/Road Scale & also

* For higher capacity Hooper Scale.



Attractive features indicates Good Self Centering with Fast Response & Strong Anti-overload Capability.

Capacity ranges from 10000kgf to 65000kgf



The Load cell is Hermetically sealed structure with IP 68.

Column type Compression Rocker Pin Load cell built from Alloy Steel & also from Stainless Steel Materials.

Specification

Application

Hopper Scales - Weighing Bridge

Cable Length

2-20 m

Capacity

30000 Kg

Compensated Temperature Range

-10 to +40 Deg C

Creep Error (30 minutes)

+/- 0.03% FS

Features

Hermetically Sealed

Ingress Protection

IP68

Insulation resistance at 50V DC

>= 1000 M Ohm

Material

Stainless Steel

Maximum Safe Overload

150% FS

Operating Temperature Range

-20 to +70 Deg C

Recommended Excitation Voltage

5 to 15V DC

Temperature Effect on Output

+/-0.010% FS/DegC

Temperature Effect on Zero

+/-0.020% FS/DegC

Ultimate Safe Overload

300% FS

Zero balance

+/- 1% FS
